Underbody Trim

Lamborghini Urus (2018-2019)

Find Your Part

Lamborghini Urus (2018-2019) - UNDERBODY TRIM

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
4M0825206J UNDERBODY TRIM $107.14 To Order
4M0825205L UNDERBODY TRIM $107.14 IN STOCK
4M0825205S UNDERBODY TRIM $149.65 IN STOCK
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
4M8825211 UNDERBODY TRIM $43.32 To Order
4M8825212 UNDERBODY TRIM $43.32 To Order
Photo Part No Description Price (each) Stock
SPEED NUT Enquire To Order
N90708803 SPEED NUT $0.73 IN STOCK
Photo Part No Description Price (each) Stock
CLIP Enquire To Order
8K0863203 CLIP $1.07 To Order
Photo Part No Description Price (each) Stock
4H0804535 SEAL $1.04 To Order
Photo Part No Description Price (each) Stock
HEAT SHIELD FOR SIDE MEMBER Enquire To Order
4M0825641E HEAT SHIELD FOR SIDE MEMBER $30.32 To Order
Photo Part No Description Price (each) Stock
WHT003207 HEXAGON PLASTIC COLLAR NUT $1.77 IN STOCK
Photo Part No Description Price (each) Stock
4M0825725D HEAT SHELF FOR CENTRE SILENCER $21.13 To Order
N90775001 HEXAGON SOCKET HEAD PANEL BOLT $1.92 To Order
Photo Part No Description Price (each) Stock
N90335004 CLAMPING WASHER $1.19 IN STOCK
1K0825951 HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING $2.68 To Order
Photo Part No Description Price (each) Stock
HEAT SHIELD FOR SIDE MEMBER Enquire To Order
4M0825642F HEAT SHIELD FOR SIDE MEMBER $30.32 To Order
4M8825211 UNDERBODY TRIM $43.32 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
N10433701 SPEED NUT $1.29 IN STOCK
Photo Part No Description Price (each) Stock
N0385494 SPREADER RIVET $0.31 IN STOCK
Photo Part No Description Price (each) Stock
N10015101 HEXAGON NUT $1.58 IN STOCK
Photo Part No Description Price (each) Stock
WHT005453 EXPANDING NUT $0.71 To Order
Photo Part No Description Price (each) Stock
4M0825213J UNDERBODY TRIM $48.46 To Order
4M0825214J UNDERBODY TRIM $48.46 To Order
Photo Part No Description Price (each) Stock
4M0825343B BRACKET $12.11 To Order
4M0825343C BRACKET $75.45 To Order
Photo Part No Description Price (each) Stock
N01508210 HEXAGON COLLAR NUT $1.85 IN STOCK
Photo Part No Description Price (each) Stock
4M0804033F COVER $165.49 To Order
Photo Part No Description Price (each) Stock
N90714303 HEX. NUT WITH WASHER $2.10 To Order
Photo Part No Description Price (each) Stock
4M0825912 GUARD PLATE $153.44 To Order
Photo Part No Description Price (each) Stock
N10609201 HEXAGON COLLAR NUT $0.41 IN STOCK
Photo Part No Description Price (each) Stock
WHT004907 RIVETTED CAP NUT $1.96 To Order
Photo Part No Description Price (each) Stock
N10642101 HEX COLLARED BOLT $0.90 To Order
Photo Part No Description Price (each) Stock
4M0825219E UNDERBODY TRIM $25.37 To Order
Photo Part No Description Price (each) Stock
8K0501329 SPREADER RIVET $2.54 To Order
Photo Part No Description Price (each) Stock
4M0825725D HEAT SHELF FOR CENTRE SILENCER $21.13 To Order
N90775001 HEXAGON SOCKET HEAD PANEL BOLT $1.92 To Order
Photo Part No Description Price (each) Stock
N90335004 CLAMPING WASHER $1.19 IN STOCK
1K0825951 HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING $2.68 To Order
Photo Part No Description Price (each) Stock
4M1825643F HEAT SHIELD FOR SIDE MEMBER $22.58 To Order
4M0825642F HEAT SHIELD FOR SIDE MEMBER $30.32 To Order
Photo Part No Description Price (each) Stock
4M1825644E HEAT SHIELD FOR SIDE MEMBER $22.58 To Order
Photo Part No Description Price (each) Stock
4M0825691F HEAT SHIELD FOR TUNNEL $34.23 To Order
4M0825692D HEAT SHIELD FOR TUNNEL $34.23 To Order
N90708803 SPEED NUT $0.73 IN STOCK
Photo Part No Description Price (each) Stock
4M0825661N HEAT SHIELD FOR TUNNEL $40.47 To Order
4M0825662J HEAT SHIELD FOR TUNNEL $40.47 To Order
CLIP Enquire To Order
...and 1 more part variants. See table on right for more details.
View All
UNDERBODY TRIM of Lamborghini Lamborghini Urus (2018-2019) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 4M0825206J
UNDERBODY TRIM
RIGHT 		$107.14 1
1 4M0825205L
UNDERBODY TRIM
LEFT
IN STOCK 		$107.14 1
1 4M0825205S
UNDERBODY TRIM
DUNE PACK-LEFT
IN STOCK 		$149.65 1
1 4M0825206M
UNDERBODY TRIM
DUNE PACK-RIGHT 		$104.77 1
2 4M8825211
UNDERBODY TRIM
LEFT 		$43.32 1
2 4M8825212
UNDERBODY TRIM
RIGHT 		$43.32 1
3 SPEED NUT
NOT USED FROM VIN 03664 		- - Enquire
3 N90708803
SPEED NUT
UNTIL VIN ZPBUA1ZL1KLA 03663-5
IN STOCK 		$0.73 (90% off) 1
4 CLIP
NOT USED FROM VIN 03664 		- - Enquire
4 8K0863203
CLIP
UNTIL VIN ZPBUA1ZL1KLA 03663 		$1.07 1
5 4H0804535
SEAL 		$1.04 2
6 HEAT SHIELD FOR SIDE MEMBER
NOT USED FROM VIN 03664 		- - Enquire
6 4M0825641E
HEAT SHIELD FOR SIDE MEMBER
UNTIL VIN ZPBUA1ZL1KLA 03663-LEFT 		$30.32 1
7 WHT003207
HEXAGON PLASTIC COLLAR NUT
T5
IN STOCK 		$1.77 (75.8% off) 23
8 4M0825725D
HEAT SHELF FOR CENTRE SILENCER
0E20K01A2 		$21.13 1
8 N90775001
HEXAGON SOCKET HEAD PANEL BOLT
4,8X16 		$1.92 36
9 N90335004
CLAMPING WASHER
5X30
IN STOCK 		$1.19 (83.4% off) 1
9 1K0825951
HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING
M6X20 		$2.68 4
10 HEAT SHIELD FOR SIDE MEMBER
NOT USED FROM VIN 03664 		- - Enquire
10 4M0825642F
HEAT SHIELD FOR SIDE MEMBER
UNTIL VIN ZPBUA1ZL1KLA 03663-RIGHT 		$30.32 1
10 4M8825211
UNDERBODY TRIM
LEFT 		$43.32 1
10 4M8825212
UNDERBODY TRIM
RIGHT 		$43.32 1
11 N10433701
SPEED NUT
4,8X18,6X16
IN STOCK 		$1.29 17
12 N0385494
SPREADER RIVET
8X12-8X12
IN STOCK 		$0.31 4
13 N10015101
HEXAGON NUT
IN STOCK 		$1.58 (78.3% off) 6
14 WHT005453
EXPANDING NUT
5X15,3 		$0.71 10
15 4M0825213J
UNDERBODY TRIM
LEFT-LEFT 		$48.46 1
15 4M0825214J
UNDERBODY TRIM
RIGHT-RIGHT 		$48.46 1
16 4M0825343B
BRACKET
FROM VIN ZPBUA1ZL5KLA 02579-LEFT 		$12.11 1
16 4M0825343C
BRACKET
UNTIL VIN ZPBUA1ZL5KLA 02578-LEFT 		$75.45 1
17 N01508210
HEXAGON COLLAR NUT
M6
IN STOCK 		$1.85 1
18 4M0804033F
COVER 		$165.49 1
19 N90714303
HEX. NUT WITH WASHER
M6 		$2.10 1
20 4M0825912
GUARD PLATE 		$153.44 -
21 N10609201
HEXAGON COLLAR NUT
M8
IN STOCK 		$0.41 (94.4% off) 4
22 WHT004907
RIVETTED CAP NUT
M8 		$1.96 2
23 N10642101
HEX COLLARED BOLT
M8X25 		$0.90 (87.4% off) 4
24 4M0825219E
UNDERBODY TRIM
RIGHT REAR 		$25.37 1
25 8K0501329
SPREADER RIVET 		$2.54 1
26 4M0825725D
HEAT SHELF FOR CENTRE SILENCER 		$21.13 1
26 N90775001
HEXAGON SOCKET HEAD PANEL BOLT
4,8X16 		$1.92 36
27 N90335004
CLAMPING WASHER
5X30
IN STOCK 		$1.19 (83.4% off) 1
27 1K0825951
HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING
M6X20 		$2.68 4
28 4M1825643F
HEAT SHIELD FOR SIDE MEMBER
LHD 		$22.58 1
28 4M0825642F
HEAT SHIELD FOR SIDE MEMBER
UNTIL VIN ZPBUA1ZL1KLA 03663-RIGHT 		$30.32 1
29 4M1825644E
HEAT SHIELD FOR SIDE MEMBER
LHD 		$22.58 1
30 4M0825691F
HEAT SHIELD FOR TUNNEL
LEFT REAR 		$34.23 1
30 4M0825692D
HEAT SHIELD FOR TUNNEL
RIGHT REAR 		$34.23 1
30 N90708803
SPEED NUT
UNTIL VIN ZPBUA1ZL1KLA 03663-5
IN STOCK 		$0.73 (90% off) 3
31 4M0825661N
HEAT SHIELD FOR TUNNEL
LEFT 		$40.47 1
31 4M0825662J
HEAT SHIELD FOR TUNNEL
RIGHT 		$40.47 1
31 CLIP
NOT USED FROM VIN 03664 		- - Enquire
31 8K0863203
CLIP
UNTIL VIN ZPBUA1ZL1KLA 03663 		$1.07 1
