Cooling System For Gear Oil

Lamborghini Urus (2018-2019)

Find Your Part

Lamborghini Urus (2018-2019) - COOLING SYSTEM FOR GEAR OIL

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
8-SPEED AUTOMATIC GEARBOX Enquire To Order
Photo Part No Description Price (each) Stock
9E409069 O-RING $10.35 To Order
Photo Part No Description Price (each) Stock
8W0317021C GEAR OIL COOLER $243.48 To Order
Photo Part No Description Price (each) Stock
N10196103 OVAL SOCKET HEAD BOLT WITH HEX DRIVE $1.26 IN STOCK
Photo Part No Description Price (each) Stock
4M0317021G GEAR OIL COOLER $428.64 To Order
Photo Part No Description Price (each) Stock
N10196103 OVAL SOCKET HEAD BOLT WITH HEX DRIVE $1.26 IN STOCK
PIPE Enquire To Order
Photo Part No Description Price (each) Stock
4N0317818H OIL PRESSURE LINE $97.27 To Order
Photo Part No Description Price (each) Stock
N90666003 O-RING $4.37 IN STOCK
Photo Part No Description Price (each) Stock
4N0317817H OIL PRESSURE LINE $100.33 To Order
Photo Part No Description Price (each) Stock
N90686902 SPRING BAND CLAMP $5.40 IN STOCK
Photo Part No Description Price (each) Stock
N91142201 SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD $1.18 To Order
Photo Part No Description Price (each) Stock
N90687001 SPRING BAND CLAMP $7.14 IN STOCK
Photo Part No Description Price (each) Stock
4M0122448J COOLANT HOSE $46.61 To Order
Photo Part No Description Price (each) Stock
3C0121093D HOSE BRACKET $4.70 To Order
Photo Part No Description Price (each) Stock
N90686901 SPRING BAND CLAMP $0.88 IN STOCK
Photo Part No Description Price (each) Stock
N90687001 SPRING BAND CLAMP $7.14 IN STOCK
Photo Part No Description Price (each) Stock
4M0121305BC SOLENOID VALVE WITH HOLDER $159.80 To Order
Photo Part No Description Price (each) Stock
N10124309 OVAL HEXAGON SOCKET HEAD BOLT $0.79 To Order
Photo Part No Description Price (each) Stock
4M0121651A HEAT REFLECTIVE MAT $11.16 To Order
Photo Part No Description Price (each) Stock
N90958903 HEXAGON SOCKET OVAL HEAD BOLT (COMBI) $1.46 To Order
Photo Part No Description Price (each) Stock
COOLANT PIPE Enquire To Order
Photo Part No Description Price (each) Stock
4M0121056AQ COOLANT HOSE $10.77 To Order
Photo Part No Description Price (each) Stock
COOLANT PIPE Enquire To Order
Photo Part No Description Price (each) Stock
4M0121444D COOLANT HOSE $10.29 To Order
Photo Part No Description Price (each) Stock
4M0121449ED COOLANT HOSE $6.08 To Order
Photo Part No Description Price (each) Stock
4M0121485CQ COOLANT PIPE $60.69 To Order
Photo Part No Description Price (each) Stock
N91096701 OVAL HEXAGON SOCKET HEAD BOLT $1.54 IN STOCK
Photo Part No Description Price (each) Stock
4M0121449EC COOLANT HOSE V8HSI ATF RL 952 $6.73 To Order
Photo Part No Description Price (each) Stock
4M0121068Q BRACKET Z HALTER PUMPE ATF $243.48 To Order
Photo Part No Description Price (each) Stock
N01508210 HEXAGON COLLAR NUT $1.85 IN STOCK
Photo Part No Description Price (each) Stock
4M0121449EB COOLANT HOSE V8HSI ATF RL $9.07 To Order
Photo Part No Description Price (each) Stock
4M0121449EE COOLANT HOSE $14.54 To Order
View All
COOLING SYSTEM FOR GEAR OIL of Lamborghini Lamborghini Urus (2018-2019) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 8-SPEED AUTOMATIC GEARBOX
SEE ILLUSTRATION AND REF.:- 300-010,1 		- - Enquire
2 9E409069
O-RING 		$10.35 2
3 8W0317021C
GEAR OIL COOLER 		$243.48 1
4 N10196103
OVAL SOCKET HEAD BOLT WITH HEX DRIVE
M6X18-M6X18
IN STOCK 		$1.26 3
5 4M0317021G
GEAR OIL COOLER 		$428.64 1
6 N10196103
OVAL SOCKET HEAD BOLT WITH HEX DRIVE
M6X18
IN STOCK 		$1.26 3
6 PIPE
SEE ILLUSTRATION : 121.07 		- - Enquire
7 4N0317818H
OIL PRESSURE LINE
FEED-FEED 		$97.27 1
8 N90666003
O-RING
11,5X3
IN STOCK 		$4.37 1
9 4N0317817H
OIL PRESSURE LINE
RETURN 		$100.33 1
10 N90686902
SPRING BAND CLAMP
23X12
IN STOCK 		$5.40 1
11 N91142201
SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD 		$1.18 1
12 N90687001
SPRING BAND CLAMP
27X12
IN STOCK 		$7.14 2
13 4M0122448J
COOLANT HOSE 		$46.61 1
14 3C0121093D
HOSE BRACKET
23-23 		$4.70 1
15 N90686901
SPRING BAND CLAMP
23X12
IN STOCK 		$0.88 9
16 N90687001
SPRING BAND CLAMP
27X12
IN STOCK 		$7.14 4
17 4M0121305BC
SOLENOID VALVE WITH HOLDER 		$159.80 1
18 N10124309
OVAL HEXAGON SOCKET HEAD BOLT
M6X20 		$0.79 2
19 4M0121651A
HEAT REFLECTIVE MAT 		$11.16 -
20 N90958903
HEXAGON SOCKET OVAL HEAD BOLT (COMBI)
M6X16 		$1.46 (80% off) 2
21 COOLANT PIPE
SEE ILLUSTRATION :- 121-080 		- - Enquire
22 4M0121056AQ
COOLANT HOSE 		$10.77 1
23 COOLANT PIPE
SEE ILLUSTRATION :- 121-000 		- - Enquire
24 4M0121444D
COOLANT HOSE 		$10.29 1
25 4M0121449ED
COOLANT HOSE 		$6.08 1
26 4M0121485CQ
COOLANT PIPE 		$60.69 1
27 N91096701
OVAL HEXAGON SOCKET HEAD BOLT
M6X16
IN STOCK 		$1.54 2
28 4M0121449EC
COOLANT HOSE V8HSI ATF RL 952
UNTIL VIN 1225 		$6.73 1
29 4M0121068Q
BRACKET Z HALTER PUMPE ATF
UNTIL VIN 1225 		$243.48 1
30 N01508210
HEXAGON COLLAR NUT
M6
IN STOCK 		$1.85 2
31 4M0121449EB
COOLANT HOSE V8HSI ATF RL
UNTIL VIN 1225 		$9.07 1
32 4M0121449EE
COOLANT HOSE 		$14.54 1
