Water Cooling System 3 of Lamborghini Lamborghini Gallardo LP560 Coupe

View All

Lamborghini Gallardo LP560 Coupe - Water Cooling System 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	N10005109	SCREW M8X35	N10005109 SCREW M8X35	$2.62	8
002	400121277	DISTANCE PIECE	400121277 DISTANCE PIECE	$9.78	8
003	400121268	RUBBER BUSH	400121268 RUBBER BUSH	$10.91	8
004	WHT001189	PLASTIC WASHER IN STOCK	WHT001189 PLASTIC WASHER IN STOCK	$5.92	8
005	WHT001942	WASHER IN STOCK	WHT001942 WASHER IN STOCK	$3.11	8
006	N10653201	HEX COLLARED BOLT IN STOCK	N10653201 HEX COLLARED BOLT IN STOCK	$1.85	8
007	400121241	LH BRACKET	400121241 LH BRACKET	$87.83	1
008	400121240	RH BRACKET	400121240 RH BRACKET	$277.10	1
009	400121232	RH BRACKET	400121232 RH BRACKET	$322.34	1
010	400121233	LH BRACKET	400121233 LH BRACKET	$96.03	1
011	400807945	LH CONVEYOR IN STOCK	400807945 LH CONVEYOR IN STOCK	$140.13	1
011	400807946	RH Conveyor IN STOCK	400807946 RH Conveyor IN STOCK	$140.13	1
012	400809964A	RH CONVEYOR IN STOCK	400809964A RH CONVEYOR IN STOCK	$357.33	1
012	400809963A	LH CONVEYOR	400809963A LH CONVEYOR	$428.64	1
013	N90986803	HEXAGON SOCKET HEAD PANEL BOLT 2 X13 IN STOCK	N90986803 HEXAGON SOCKET HEAD PANEL BOLT 2 X13 IN STOCK	$0.95	2
014	N0454281	CLIP IN STOCK	N0454281 CLIP IN STOCK	$0.87 MSRP: ~~7.24~~ (88% off)	2
015	N0902324	SCREW M6X10 IN STOCK	N0902324 SCREW M6X10 IN STOCK	$0.98 MSRP: ~~7.25~~ (86.5% off)	8
016	N10347004	SCREW M6X16 IN STOCK	N10347004 SCREW M6X16 IN STOCK	$0.93 MSRP: ~~7.27~~ (87.2% off)	8
017	WHT002225A	HEXAGON SOCKET HEAD BOLT IN STOCK	WHT002225A HEXAGON SOCKET HEAD BOLT IN STOCK	$1.35 MSRP: ~~7.16~~ (81.1% off)	6
018	N10653201	HEX COLLARED BOLT IN STOCK	N10653201 HEX COLLARED BOLT IN STOCK	$1.85	4
019	N90780903	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N90780903 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$0.93	4
020	400121235A	RH BRACKET	400121235A RH BRACKET	$192.15	1
020	400121235	LH BRACKET	400121235 LH BRACKET	$213.71	1
021	400121252D	RH WATER RADIATOR IN STOCK	400121252D RH WATER RADIATOR IN STOCK	$1,958.31	1
021	400121253D	LH WATER RADIATOR	400121253D LH WATER RADIATOR	$1,895.94	1
022	4Z7959455M	RADIATOR ELECTRIC FAN IN STOCK	4Z7959455M RADIATOR ELECTRIC FAN IN STOCK	$1,624.27	2
023	400122194C	RH Support	400122194C RH Support	$575.75	1
023	400122193C	LH SUPPORT	400122193C LH SUPPORT	$480.65	1
024	400807157C	LH CONVEYOR IN STOCK	400807157C LH CONVEYOR IN STOCK	$829.38	1
024	400807158C	RH Conveyor IN STOCK	400807158C RH Conveyor IN STOCK	$829.38	1
025	N0902324	SCREW M6X10 IN STOCK	N0902324 SCREW M6X10 IN STOCK	$0.98 MSRP: ~~7.25~~ (86.5% off)	4
026	400260197C	BRACKET	400260197C BRACKET	$69.50	1
027	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	$2.03	4
028	N10082911	SCREW M6X16 IN STOCK	N10082911 SCREW M6X16 IN STOCK	$0.64	2
029	400807265	GASKET	400807265 GASKET	$9.95	2
030	417103484	GASKET	417103484 GASKET	$7.74	4
031	420121261A	BRACKET	420121261A BRACKET	$3.50	2
032	1J0971830R	BRACKET FOR CONNECTOR HOUSING IN STOCK	1J0971830R BRACKET FOR CONNECTOR HOUSING IN STOCK	$4.89	2
033	N10347004	SCREW M6X16 IN STOCK	N10347004 SCREW M6X16 IN STOCK	$0.93 MSRP: ~~7.27~~ (87.2% off)	2
035	WHT002961	WASHER IN STOCK	WHT002961 WASHER IN STOCK	$0.39	8
036	N0115484	WASHER	N0115484 WASHER	$4.12	8
037	400121129A	SPACER HOLDER	400121129A SPACER HOLDER	$14.59	8
038	7L121585	RUBBER BUSHING	7L121585 RUBBER BUSHING	$17.89	8
039	N01508213	HEXAGON COLLAR NUT IN STOCK	N01508213 HEXAGON COLLAR NUT IN STOCK	$0.20	8
